500hm wireless data transmission rg58 coaxial cable

Payment Terms: T/T
Place of Origin: Zhejiang, China (Mainland)
inquire skype
Add to My Favorites
HiSupplier Escrow
Share |

Product Detail

Model No.: rg58
Production Capacity: 5000km
Delivery Date: in 25 day
Connector Color: Gold
Type: Coaxial
Color: Black
Means of Transport: Ocean
Packing: Carton Box
Connector Type: VGA
Application: Multimedia
Outer Diameter: Others
Brand Name: haisen

rg58 coaxial cable
1)19x0.18mm TC Conductor+2.95mm Solid PE Insulation+64x0.12mm TC 95% Braiding+4.95mm PVC Jacket

RG58 Coaxial Cable 50ohm
Specifications
TC: Tinned Copper BC: Bare Copper CCS; Copper Clad Steel
1)19x0.18mm TC Conductor+2.95mm Solid PE Insulation+112x0.12mm TC 95% Braiding+4.95mm PVC Jacket
2)Customers' specifications are wellcomed.
Note:
1) Center conductor: TC, BC, and CCS available;
2) Al-foil: Non-bonded Al-foil, bonded Al-foil, double bonded Al-foil, and double non-bonded Al-foil are available;
3) Braiding wire: AL, BC and TC available;
4) Braiding wire diameter: 0.10, 0.12, 0.13, 0.14, 0.15, 0.16mm available;
5) Braiding net: 80, 96, 120, 128, 144 and more available;
6) Braiding coverage: Between 30- 97% available;
7) PVC jacket of Flame retardant, UV, or UL available.
Characteristics:
Impedance: 50+/-2 Ohm
Velocity of Propagation: 66%
Capacitance: 93.5pF/m
Return Loss: 23dB min
Attenuation: [@68 F. (20 C) ] dB/100meters
50MHz: 5.0dB 500MHz: 46.5dB
100MHz: 12.2dB 700MHz: 58.0dB
200MHz: 17.8dB 800MHz: 63.8dB
300MHz: 26.60dB 1000MHZ: 75.0dB
400MHz: 40.7dB

Packing:
1) Packing Lengths: 100m/roll, 200m/roll, 305m/roll, 100yard/roll, 200yard/roll, 300yard/roll. Other lengths according to client's request.
2) Inner packing: Wooden reel, plastic reel, and paper reel.
3)Outer Packing: Wooden Drum, Carton Box, Pull Out Box
Other packing available according to customers' request
